MODEL | STB105 | STB125 | STB145 | STB165 |
DIMENSIONS(L*W*H) | 1160x1330x920mm | 1360x1330x920mm | 1560x1330x920mm | 1760x1330x920mm |
STRUCTURE WEIGHT | 330kg | 355kg | 380kg | 405kg |
WORKING WIDTH | 950mm | 1150mm | 1350mm | 1550mm |
WORKING DEPTH | 120mm | 120mm | 120mm | 120mm |
WORKING EFFICIENCY | 1500-2000㎡/h | 1800-2400㎡/h | 2100-2800㎡/h | 2400-3200㎡/h |
PTO TURNNING SPEED | 540r/min | 540r/min | 540r/min | 540r/min |
PTO SPLINE | 6x8x700mm | 6x8x700mm | 6x8x700mm | 6x8x700mm |
POWER REQUIRED | 20-28hp | 25-30hp | 28-40hp | 35-45hp |
